New SmartCtrl Version!

Find what’s new in SmartCtrl 3.0

What's new

SmartCtrl 3.0

SmartCtrl
The fast and efficient way of designing

the control for your power converter

Design your converter with just one click

and optimize its control in minutes

One test is worth a million words

Start your free trial!

Demo

banner_analog

All components of the loop

have been modeled

Key components of the loop

are commercial IC

Features

banner SmartCtrl

Digital effects are

considered in the design

Get a digital control for your converter and

analyze the differences with the analog control

Features

banner_teaching4

Teach with SmartCtrl

The easier way of teaching how to design

the control in power electronics applications

Education

Why Should I Use SmartCtrl?

Simple


smartctrl_marcador_listas  Friendly user interface
smartctrl_marcador_listas  Steady-state waveforms
smartctrl_marcador_listas  Solution Map for easy controller design
smartctrl_marcador_listas  Interactive plots

Versatile

smartctrl_marcador_listas  DC-DC converters
smartctrl_marcador_listas  Power Factor Correction Converters
smartctrl_marcador_listas  Different control modes
smartctrl_marcador_listas  Any converter control can be designed

In-depth Knowledge

_

smartctrl_marcador_listas  Multi-loop control structure
smartctrl_marcador_listas  Capability to design digital controllers
smartctrl_marcador_listas  Sensitivity analysis
smartctrl_marcador_listas  Audio-susceptibility

The fast and efficient way of designing the control for your power converter

Control Designs from Specs

Starting from a specification, design quickly and visually the best control for your converter, with result feedback for both analog and digital controls

learn more…

smartctrl_Control Design
smartctrl_multi-loop

Multi-Loop Control Structures

Both Average-Current Mode Control and Peak-Current Mode Control are supported in SmartCtrl, providing greater scope in design

learn more…

Optimize Your Design using the Solutions Map

Navigate the cursor within a stable solutions space, which aids in your selection of the optimal design

learn more…

smartctrl_rt1
smartctrl_robust

Analyze How Robust Your Control Is

Does your control remain stable when the input voltage changes? SmartCtrl’s Parametric Sweep feature allows you to carry out sensitivity analysis of every parameter of the plant, sensor and regulator

learn more…

Create and Edit Your Own Analytical Model

With the Equation Editor, you can customize your own analytical model for your specific converter. The design tools of SmartCtrl then help you to calculate the compensator required

learn more…

smartctrl_analytical-model
smartctrl_analog2

Analog and Digital Control are Supplied

Design the control of your converter directly in the digital domain or, alternatively, transform an analog control to digital and then examine the effect of sampling frequency, digital delay, bits number, etc.

learn more…

Detailed Outputs

SmartCtrl provides detailed information about the designed compensator (resistor, capacitors or z-domain coefficients), as well as the power stage and steady-state waveforms. Reports can be generated automatically and every plot can be exported efficiently (as an image or data points)

learn more…

smartctrl_detailed
SmartCtrl®: a friendly interface, simple workflow, and transparent display of control loop stability and performance
smartctrl_realimentation
The fast and efficient way of designing the control for your power converter
smartctrl_negativo4

Customers

SmartCtrl customers include:
